Moto Guzzi V9 Bobber

Ex-Showroom Price

₹ 13,60,000
* Delhi. May vary.

USER OPINION

QUICK FACTS & SUMMARY
Body Type Cruiser
Fuel Type Petrol
Shades Black, Silver
ENGINE SPECIFICATIONS
Engine Description 90° V-twin, 4-stroke, 2-valves per cylinder
Fuel System Marelli MIU single-body electronic injection
Cooling Air + Oil cooling
Displacement 853 cc
Maximum Power 55 HP @ 6250 rpm
Maximum Torque 62 NM @ 3000 rpm
Number of Cylinders 2
Emission Standard Euro 4
Compression Ratio 10.5: 1
Bore 84 mm
Stroke 77 mm
GEARBOX & CLUTCH
Primary drive Primary drive with helical teeth, ratio 21/25 = 1: 1.190
Number of Gears 6
Clutch 170 mm single disc with integrated flexible couplings
Gear Ratios 1st 16/39 = 1:2.437, 2nd 18/32 = 1:1.778, 3rd 21/28 = 1:1.333, 4th 24/26 = 1:1.083, 5th 25/24 = 1:0.96, 6th 28/24 = 1:0.857
Final Drive Double universal joint and double bevel gear units (8/33 ratio = 1: 4,125
DIMENSIONS & WEIGHT
Overall Length 2124 mm
Overall Width 892 mm
Overall Height 1100 mm
Seat Height 745 mm
Wheelbase 1480 mm
Kerb/Wet Weight 199 kg
Fuel Tank Capacity 15 litres
Reserve Fuel Capacity 4 litres
BRAKES & SAFETY
Front Brake Stainless steel floating disc, Ø 320 mm Brembo opposed four-piston callipers
Rear Brake Stainless steel floating disc, Ø 260 mm Brembo opposed two-piston callipers
Anti-lock Braking System (ABS) Brembo with Dual channel Continental ABS system
SUSPENSION & WHEEL TRAVEL
Front Suspension Traditional fork, Ø 40 mm
Rear Suspension Swingarm with double shock absorber with adjustable spring preload
Front Wheel Travel 130 mm
Rear Wheel Travel 97 mm
TYRE SIZE & WHEELS
Front Tyre 130/90 R 16"
Rear Tyre 150/80 R 16"
Front Wheel 2.50" x 19"
Rear Wheel 4.00" x 16"
Wheel Type Aluminium alloy
INSTRUMENT CONSOLE FEATURES
Speedometer Analog
Tachometer
Trip Meter Digital
Odometer Digital
Clock Digital
ABS Light
Fuel Gauge Digital
COMFORT & CONVENIENCE FEATURES
Pillion Backrest
Electric Start
Pillion Grabrail
Pass Light
Engine Kill Switch
Pillion Footrest
BATTERY & ELECTRICALS
Battery Type MF
Capacity 18 Ah
Voltage 12 V
Miscellaneous Information
Exhaust/Muffler Stainless steel, 2-in-2 type, three-way catalytic converter with double lambda probe
Frame/Chassis ALS steel twin tube cradle frame
Trail 125.1 mm (116.1 mm)
Steering Angle 38°
