Honda CB500F
Expected Price
₹ 4,00,000 - ₹ 4,25,000
* Delhi. May vary.
Expected
Specifications
See full specifications
| Displacement | 471 cc |
| Maximum Power | 46.9 Bhp @ 8500 rpm |
| Maximum Torque | 43 Nm @ 7000 rpm |
| No. of Cylinders | 2 |
| No. of Gears | 6 |
| Seat Height | 790 mm |
| Ground Clearance | 155 mm |
| Kerb/Wet Weight | 190 kg |
| Fuel Tank Capacity | 15.7 litres |
| Top Speed | 168 kmph |
More Bikes By Honda
Honda India
QUICK FACTS | |
| Expected Price | Rs 4 lakh |
| Launch Date | Not Announced Yet |
| Type | Naked |
| Status | Upcoming |
| Shades | Black, Pearl White |
| Official Tagline | A More Comfortable Sportbike |
| Frame/Chassis | Diamond type steel |
ENGINE, POWER & TORQUE | |
| Displacement | 471 cc |
| Maximum Power | 46.9 Bhp @ 8500 rpm |
| Maximum Torque | 43 Nm @ 7000 rpm |
| Engine Description | Liquid-cooled, 4-stroke, DOHC 8-valve, water-cooled |
| Cooling | Liquid Cooling |
| Fuel System | PGM-FI electronic fuel injection |
| Ignition | Digital with electronic advance |
| Compression Ratio | 10.7 : 1 |
| Bore | 67 mm |
| Stroke | 66.8 mm |
| No. of Cylinders | 2 |
| Valve System | 4 valves per cylinder |
| Fuel Type | Petrol |
| Engine Weight | 52.7 kg |
TRANSMISSION | |
| No. of Gears | 6 |
| Clutch | Multi plate wet |
| Final Drive | Chain |
BRAKES | |
| Front Brake | Single Wavy Disk, 320mm, 2 POT caliper |
| Rear Brake | Single Wavy Disk, 240mm, 1 POT caliper |
| Anti-lock Braking System (ABS) | |
SUSPENSION | |
| Front Suspension | Conventional Telescopic Front Forks, 41mm |
| Rear Suspension | Prolink mono with 9-stage Preload adjuster, steel square pipe swingarm |
| Front Wheel Travel | 120mm |
| Swing Arm Length | 567.7 mm |
WHEELS & TYRES | |
| Front Tyre | 120/70ZR - 17M/C |
| Rear Tyre | 160/60ZR - 17M/C |
| Front Wheel | Multi-Spoke Aluminium Cast, MT 3.5 -17 |
| Rear Wheel | Multi-Spoke Aluminium Cast, MT 4.5 - 17 |
| Wheel Type | Alloys |
| Tubeless Tyres | |
| Alloy Wheels | |
BATTERY | |
| Battery Type | Maintenance Free |
| Capacity | 8.6 Ah |
| Voltage | 12V |
DIMENSIONS, WEIGHT & CAPACITIES | |
| Overall Length | 2075 mm |
| Overall Width | 780 mm |
| Overall Height | 1060 mm |
| Seat Height | 790 mm |
| Ground Clearance | 155 mm |
| Wheelbase | 1410 mm |
| Dry Weight | 173.4 kg |
| Kerb/Wet Weight | 190 kg |
| Fuel Tank Capacity | 15.7 litres |
| Oil tank capacity | 3.2 litres |
| Front/Rear Weight Distribution | 47.8:52.2 / 47.8:52.2 |
PERFORMANCE & MILEAGE | |
| Top Speed | 168 kmph |
| Mileage (Certified) | 27 kmpl |
INSTRUMENT CONSOLE | |
| Speedometer | Digital |
| Tachometer | Digital Bar Graph |
| Trip Meter | Analog-2 |
| Fuel Consumption Gauge | Digital |
| Clock | |
| Fuel Gauge | Digital |
COMFORT & CONVENIENCE | |
| Electric Start | |
| Pillion Footrest | |
| Pass Light | |
| Step-up Seat/Split Seat | |
| Security System | HISS (Honda Intelligent Security System) |
OTHER SPECIFICATIONS | |
| ACG Output | 23.4A/2000rpm |
| Exhaust/Muffler | 2-1 manifold with Catalyst and 02 feedback |
| Caster Angle | 25.5 degrees |
| Trail | 101.9 |
LIGHTING | |
| Head Light | Irregular Shape, 60/55W x 1 light |
| Tail Light | 1 Light (Bulb) |
