Harley-Davidson Fat Boy Special vs Harley-Davidson Fat Bob Comparison
Updated: 08, Nov, 2023 08:52 AM
Ex-Showroom Price
₹ 15,54,000
* Delhi. May vary.
Discontinued
POPULARITY
|
Ex-Showroom Price
₹ 20,49,000
* Delhi. May vary.
POPULARITY
|
||
DIMENSIONS AND WEIGHT | |||
| Kerb Weight | |||
| 330 kg | 306 kg | ||
| Ground Clearance | |||
| 125 mm | 120 mm | ||
| Fuel Tank Capacity | |||
| 18.9 litres | 13.2 litres | ||
| Wheelbase | |||
| 1630 mm | 1615 mm | ||
| Overall Length | |||
| 2385 mm | 2340 mm | ||
| Overall Width | |||
| 910 mm | NA | ||
| Overall Height | |||
| 1085 mm | NA | ||
| Seat Height | |||
| 670 mm | 710 mm | ||
| Engine Oil Capacity | |||
| 3.3 litres | 4.7 litres | ||
| Dry Weight | |||
| 318 kg | 296 kg | ||
COMFORT FEATURES | |||
| Electric Start | |||
| Pillion Footrest | |||
| Step-up Seat/Split Seat | |||
| Security System | |||
| Optional | NA | ||
MILEAGE AND TOP SPEED | |||
| Mileage | |||
| 17.8 kmpl (approx.) | Harley-Davidson Fat Bob mileage is 18.18 kmpl. | ||
ENGINE AND GEARBOX | |||
| Engine cc (Displacement) | |||
| 1585 cc | 1868 cc | ||
| Bore | |||
| 95.3 mm | 102 mm | ||
| Stroke | |||
| 111.1 mm | 114.3 mm | ||
| Compression Ratio | |||
| 9.2:1 | 10.5:1 | ||
| Engine Torque Testing Method | |||
| EEC/95/1 | EC 134/2014 | ||
| Engine Diagnostics Readout | |||
| Number of Cylinders | |||
| 2 | 2 | ||
| Engine Details | |||
| Air-cooled, Twin Cam 103B | 1868cc, Air-Cooled, Milwaukee-Eight 114, V-Twins Cylinder Engine | ||
| Maximum Power | |||
| 61 Bhp @ 5200 rpm | 93 HP @ 5020 rpm | ||
| Maximum Torque | |||
| 132 Nm @ 3250 rpm | 155 Nm @ 3500 rpm | ||
| Number of Gears | |||
| 6 | 6 | ||
| Cooling | |||
| Air Cooling | Air Cooled | ||
| Primary drive | |||
| Chain, 34/46 ratio | Chain, 34/46 Ratio | ||
| Gear Ratios | |||
| 1st - 9.311, 2nd - 6.454, 3rd - 4.793, 4th - 3.882, 5th - 3.307, 6th - 2.79 | 1st - 9.311, 2nd - 6.454, 3rd - 4.793, 4th - 3.882, 5th - 3.307, 6th - 2.79 | ||
INSTRUMENT CONSOLE FEATURES | |||
| Low Oil Pressure Light | |||
| Low Fuel Warning Light | |||
| RPM/Gear Display | |||
| NA | |||
| LED Indicator Lights | |||
| NA | |||
| Fuel Gauge | |||
| fuel gauge with low fuel warning light and countdown feature | Digital | ||
| Tachometer | |||
| Analog | Analogue | ||
| Trip Meter | |||
| Digital-2 | Digital | ||
| Speedometer | |||
| Tank-mounted electronic speedometer | Digital | ||
| Odometer | |||
| time-of-day clock on odometer | Digital | ||
BATTERY AND LIGHTING | |||
| Pass Light | |||
| Turn Signal Light (Front) | |||
| LED | |||
| Battery Type | |||
| Maintenance Free | MF | ||
BRAKES AND TYRES | |||
| Tubeless Tyres | |||
| NA | |||
| Front Brake | |||
| 4-piston | Dual Disc | ||
| Alloy Wheels | |||
| NA | |||
| Rear Brake | |||
| 2-piston | Disc | ||
| Wheel Type | |||
| Silver, Bullet Hole Disc Cast Aluminum | Denim Black, Structure Cast Aluminium with Laser Etched Graphics | ||
| Front Tyre | |||
| 140/75R17 67V | 150/80-16,71H,BW | ||
| Rear Tyre | |||
| 200/55R17 78V | 180/70-B16,77H,BW | ||
| Front Wheel | |||
| Black, Bullet Hole Disc Cast Aluminum | NA | ||
| Rear Wheel | |||
| Black, Bullet Hole Disc Cast Aluminum | NA | ||
SUSPENSION AND CHASSIS | |||
| Front Suspension | |||
| 41.3mm telescopic | Single Cartridge 43mm Inverted with Aluminum Fork Triple Clamps; Triple Rate Spring | ||
| Rear Suspension | |||
| Hidden, horizontal-mounted, coil-over | Hidden, Free Piston, Coil-Over Monoshock; 56mm Stroke; Toolless Hydraulic Preload Adjustment | ||
| Exhaust/Muffler | |||
| Denim Black and Satin Chrome, over/under shotgun exhaust with dual mufflers | 2-into-2 Shorty Dual, Catalyst in Muffler | ||
Miscellaneous Information | |||
| Lean Angle, Right (deg.) | |||
| 25.6 Degrees | 31 Degree | ||
| Rake | |||
| 31.6 Degrees | 28 Degree | ||
| Trail | |||
| 147 mm | 132 mm | ||
Colour Options and Price in India | |||
| 2-Wheeler Type | |||
| Cruiser | Cruiser | ||
| Colour Options | |||
| Vivid Black, Silver Pearl | Vivid Black, Redline Red, Gray Haze | ||
| Fuel Type | |||
| Petrol | Petrol | ||
