Yamaha SZ

Yamaha SZ

 POPULARITY

  • This week: 27 views
  • All time: 266478 views

Ex-Showroom Price

₹ 60,307 - ₹ 66,064
* Delhi. May vary.

USER OPINION

GENERAL INFORMATION
Note Above mentioned price of Yamaha SZ-RR V2 is ex-showroom (Delhi). Price may vary as per applicable state taxes/octroi etc. Please collect exact price details from your nearest Yamaha authorized dealer.
Bike Category (cc) 125cc-150cc
Highlights (Key Features) Powerful engine, disc brake, stylish & robust design, wide comfortable seat, large fuel tank, split grab bar
Type Sports Commuter
Status Available
Official Tagline New Innovation for a New Impression. Stay Ahead!
Shades/Colors Ivory Green, Red Dash, Green Arrow
Frame/Chassis Diamond-type
ENGINE, POWER & TORQUE
Displacement 149 cc
Maximum Power 11.9 Bhp @ 7500 rpm
Maximum Torque 12.8 Nm @ 6000 rpm
Engine Description Air cooled, 4-stroke, SOHC, 2-valve
Cooling Air-cooled
Fuel System Carburetor
Lubrication Wet sump
Compression Ratio 9.5:1
Bore 57.3 mm
Stroke 57.9 mm
Number of Cylinders 1
Cylinder Layout Single cylinder
TRANSMISSION
Gearbox 5-speed constant mesh
Clutch Wet, multiple-disc
Gear Ratios 1st=2.714, 2nd=1.789, 3rd=1.318, 4th=1.045, 5th=0.916
Primary Reduction Ratio 3.409
Secondary Reduction Ratio 3.000
Final Drive Chain
Shift Type Return
BRAKES
Front Brake 245 mm Hydraulic Disc
Rear Brake 130 mm Drum
SUSPENSION
Front Suspension Telescopic with coil spring & oil damper
Rear Suspension Swingarm with coil spring & oil damper
Front Wheel Travel 135mm
Rear Wheel Travel 120mm
Inner tube diameter of front fork 33 mm
WHEELS & TYRES
Front Tyre 2.75-17M/C 41P
Rear Tyre 100/90-17M/C 55P
Wheel Size 17-inch
Tubeless Tyres
Alloy Wheels
BATTERY
Battery Type MF
Capacity 5AH (10H)
Voltage 12V
DIMENSIONS, WEIGHT & CAPACITIES
Overall Length 2050 mm
Overall Width 760 mm
Overall Height 1100 mm
Ground Clearance 165 mm
Seat Height 800 mm
Wheelbase 1320 mm
Kerb/Wet Weight 134 kg
Fuel Tank Capacity 14 litres
Oil tank capacity 1.2 litres
Turning Circle 4.8
INSTRUMENT CONSOLE
Speedometer Analog
Tachometer Analog
Odometer Analog
Fuel Gauge Analog
COMFORT & CONVENIENCE
Electric Start
Pillion Footrest
OTHER SPECIFICATIONS
Caster Angle 26°
Trail 99 mm
LIGHTING
Head Light Halogen (12V.35/35Wx1)
Tail Light 12V.21/5Wx1
Turn Signal Light (Front) 12V.10Wx2
Turn Signal Light (Rear) 12V.10Wx2
Auxiliary Light 12V.5Wx1

Yamaha SZ Review

08 May, 2015 11:08 AM

Quick Facts

Yamaha SZ-RR Version 2.0 - New Innovation for the New Impression. Stay Ahead!
