TVS Apache FX
Specifications
See full specifications
| 2-Wheeler Type | Sports |
| Engine cc (Displacement) | 313 cc |
| Maximum Power | 33.6 BHP @ 9500 rpm |
| Maximum Torque | 28 NM @ 7500 rpm |
| Number of Cylinders | 1 |
| Number of Gears | 6 |
Colour Options and Price in India | |
| 2-Wheeler Type | Sports |
| Fuel Type | Petrol |
MAXABOUT RATING AND OVERVIEW | |
| Vehicle Overview | TVS Apache RTR 300 is an expected model that is said to be based on the Akula 310. It would carry a full faired design and use the 313cc engine from the BMW G310R, producing 33.6 BHP and 28 Nm of torque. It may claim a top speed of around 145 kmph and would use LED front headlight, ABS and all important features in the present market scenario. |
ENGINE AND GEARBOX | |
| Engine Details | Water-cooled, single-cylinder 4-stroke engine, four valves, two overhead camshafts, dry sump lubrication |
| Engine cc (Displacement) | 313 cc |
| Maximum Power | 33.6 BHP @ 9500 rpm |
| Maximum Torque | 28 NM @ 7500 rpm |
| Number of Cylinders | 1 |
| Emission Norms | Closed-loop 3-way catalytic converter, emission standard EU-4 |
| Compression Ratio | 10.6 : 1 |
| Bore | 80 mm |
| Stroke | 62.1 mm |
| Engine Management | Electronic fuel injection, BMS-E2 |
| Number of Gears | 6 |
| Clutch | Multiple-disc clutch in oil bath, mechanically operated |
| Gear Ratios | 1st - 3.000, 2nd - 2.063, 3rd - 1.588, 4th - 1.286, 5th - 1.095, 6th - 0.955 |
| Final Drive | Endless O-ring chain with shock damping in rear wheel hub |
| Primary Gear Ratio | 3.083 |
| Gear Pattern | 1-down, 5-up |
BRAKES AND TYRES | |
| Front Brake | Single disc, diameter 300 mm, 4-piston fixed caliper, radially bolted |
| Rear Brake | Single disc, diameter 240 mm, single-piston floating caliper |
| ABS | BMW Motorrad ABS |
| Front Tyre | 110/70 R17 |
| Rear Tyre | 150/60 R17 |
| Front Wheel | 3.0 x 17" |
| Rear Wheel | 4.0 x 17" |
| Wheel Size | 17-inch |
| Wheel Type | Cast aluminium wheels |
| Tubeless Tyres | |
| Alloy Wheels | |
SUSPENSION AND CHASSIS | |
| Front Suspension | Upside down fork , Ø 41 mm |
| Rear Suspension | Solid die-cast aluminum swingarm, directly hinged monoshock, adjustable preload |
| Frame (Chassis) | Bolted steel frame, drive unit load-bearing, tubular steel rear frame |
| Front Wheel Travel | 140 mm |
| Rear Wheel Travel | 131 mm |
INSTRUMENT CONSOLE FEATURES | |
| Speedometer | Digital |
| Tachometer | Digital |
| Trip Meter | Digital |
| Odometer | Digital |
| Engine Temperature Gauge | |
| Fuel Consumption Gauge | |
| Clock | Digital |
| ABS Light | |
| RPM/Gear Display | |
| Fuel Gauge | Digital |
| Low Fuel Warning Light | |
| Gear Indicator | |
| Service Reminder | |
| Low Oil Indicator | |
| Low Battery Indicator | |
BATTERY AND LIGHTING | |
| Pass Light | |
| Battery Type | Maintenance free |
| Capacity | 8 Ah |
| Voltage | 12 V |
| Alternator | 330 W |
| Head Light | H4 12V 60/55W |
COMFORT FEATURES | |
| Pillion Footrest | |
| Electric Start | |
| Engine Kill Switch | |
| Pillion Grabrail | |
Miscellaneous Information | |
| Steering Angle | 64.9° |
Questions and Answers
Most Popular Answers for TVS Apache FX
What is the price of TVS Apache FX in India?
29 December 2022 05:53
TVS Apache FX is a dirt bike which is not currently on sale in India. The bike comes with a 300 cc, liquid cooled engine producing nearly 50 BHP as it gets a power value of 160 BHP/liter. The bike comes with off-road tyres and disc brakes for both the wheels. The specialities of this machine includes a aircraft grade machining on the outer tube for the front suspension with a hydraulic nitrogen gas damped rear suspension. It also gets aluminium wheel rims and comes with a high ground clearance.
