VEHICLE SUMMARY |
| Name: | Discover 135 |
| Model: | Sports |
| Type: | Commuter |
| Top Speed: | 103kph |
ENGINE SPECIFICATIONS |
| Displacement: | 134.21cc |
| Engine: | 4 Stroke, Air Cooled, DTS-i |
| Maximum Power: | 13 Bhp @ 8500 rpm |
| Maximum Torque: | 11.88 Nm @ 6500 rpm |
| Gears: | 4 Speed |
| Clutch: | Wet, Multi Plate Type |
| Bore: | NA |
| Stroke: | NA |
| Cylinder Configuration: | NA |
| Engine Block Material: | NA |
| Chassis Type: | Double Cradle Type |
| Cooling Type: | Air Cooling |
| Carburetor: | NA |
DIMENSIONS |
| Length: | 2030.00 mm |
| Width: | 760.00 mm |
| Height: | 1065.00 mm |
OTHER SPECIFICATIONS |
| Weight: | 133.00 kg |
| Ground Clearance: | 175.00 mm |
| Fuel Tank: | 10.00 ltrs |
| Wheelbase: | 1305.00 mm |
| Turn Circle: | 3.28 mtrs |
| Electrical System: | 12V |
| Headlamp: | 35/35W |
| Horn: | 12V DC |
| Wheel Type: | Alloys |
| Wheel Size: | 100/90 x 17 mm |
| Tubeless: | |
| Colors: | NA |
|
ACTIVE AND PASSIVE SAFETY |
| Suspension(Front): | Telescopic |
| Suspension(Rear): | Trailing Arm |
| Brakes: | 240mm Disc |
| Brakes(Rear): | 130mm Drum |
| Stand Alarm: | |
|
COMFORT AND CONVENIENCE |
| Fuel Guage: | Digital |
| Self Start: | |
| Tacho Meter: | Analogue |
| Trip Meter: | Digital-1 |
| Alloys: | |
| Warranty: | NA |
| Speedometer: | Digital |
| Passenger Footrest: | |
| Passenger Backrest: | |
| Step-up Seat: | |
| Pass-light: | |
| Low Fuel Indicator: | |
| Low Oil Indicator: | |
| Low Battery Indicator: | |
| High Oil Temp. Indicator: | |
| Choked Air Filter Indicator: | |
|
